Description
Specifications:
| Part No. |
Type1 (A2-1) |
Type2 (A2-2) |
Type3 (A2-3) |
Type4 (A2-4) |
| Model No. |
KFT-PTFE050N022O-PC |
KFT-PTFE050N022O-PC |
KFT-PTFE050N022O-PC |
KFT-PTFE050N022O-PC |
? |
? |
? |
? |
|
| Biosafety | Meet the requirements of USP Class VI Biological Test for plastics | |||
|
Connection |
(Accepted ID7-13mm) Hydrophobic PTFE 50mm 0.22um air filter Inlet: Stepped Hose Barb Outlet: Stepped Hose Barb |
Hydrophobic PTFE 50mm 0.22um air filter Inlet:1/8″”NPT |
(Accepted ID7-13mm) Hydrophobic PTFE 50mm 0.22um air filter Inlet: Stepped Hose Barb Outlet: 1/8″” NPT |
Hydrophobic PTFE 50mm 0.22um air filter Inlet: 1/2″”NPT Outlet: Stepped Hose Barb |
| Filtration area |
19.6cm 2 |
|||
| Air flow rate |
18-20 LPM@1kg/cm2 |
|||
| Housing size |
65mm |
|||
| Housing material |
Polycarbonate or Polypropylene |
|||
| Sterilization |
EO or Autoclave |
|||
| Pore Size | 0.22um, 0.45um, 1um or other pore size |
