Description
- HPLC Class
- Integrity tested
- Multiple choices of membranes
- Medical grade polypropylene housing
- OEM accepted
- Housing material: PP
- Filtration area: 0.12cm2
- Process Volume: 1ml
- Hold-up Volume: <10µL
- Pressure Bar (PSI): 5.2 Bar (75)
- Highest Temp.: 45′ C
- Housing Material: PP
- Filtration area: 0.65cm2
- Process Volume: 10ml
- Hold-up volume: <25µL
- Pressure Bar (PSI): 7Bar (100)
- Highest Temp.: 45′ C
- Housing Material: PP
- Filtration area: 3.9cm2
- Process Volume: 100ml
- Hold-up volume: <100µL
- Pressure Bar (PSI):5.2Bar (75)
- Highest Temp.: 45∞ C
Ordering Information:
|
1 Membrane |
2 Diameter |
3 Sterile |
4 Pore size |
5 Membrane Characteristics |
|
|
PVDF |
CA |
004=4mm |
N(non-sterile) |
020=0.20µm |
I = hydrophilic |
|
PTFE |
PES |
013=13mm |
|
022=0.22µm |
0 = hydrophobic |
|
Nylon |
RC |
030=25mm |
|
045=0.45µm |
|
|
MCE |
GF |
|
|
100=1.0µm |
|
|
100pcs/pk |
|||||
|
Example: PTFE 013 N 045 I= 13mm, Hydrophilic PTFE, 0.45um 1 2 3 4 5 |
|||||
